Qty of V12, V16 & V20 Tooling as lotted

Combination of lots 1 & 1B

Lot 1 - Bystronic ByBend Smart 225/4100 Hydraulic Pressbrake. S/No. BYBEND22335SE (10/2022), Max Pressure Force 2250KN, Working Length 4100mm, Max Stoke 300mm, Machine Weight 16,500kg

Lot 1A - Qty of V12, V16 & V20 Tooling, as lotted

D’Andrea Facing Head

Combination of lots 1, 1A & 1B

Lot 1 - Doosan HM1000 Heavy Duty Twin Pallet Horizontal Machine Centre. S/No HM10000080 (11.2009) with Fanuc 31i model A Control, Pallet size 1000mm x 1000mm, Travels X = 2100mm, Y = 1250mm, Z = 1250mm, Big Plus Spindle BT50, Spindle speeds 20 – 6000 rpm, RUCKLE Full ‘B’ axis, Max Table load 5000 kg (upgrade capacity), ATC Carousel 90 positions, U Axis fitted to Spindle for D-Andrea Heads, Renishaw TS27R Tool Probe, Renishaw RMP 60 Spindle Probe, Qty of BT50 Toolholders (Backend only), Screw Drive Swarf Conveyor, Filtermist, Main Spindle refurbished in 2020, Machine Weight 29,000kgs. Country of Origin: Korea

Lot 1A - D’Andrea Facing Head

Lot 1B - D’Andrea Facing Head

Mazak Integrex E-650H x 2000 CNC Multi-Tasking CNC Lathe. S/No. 168658 (2004) with Mazatrol Fusion 640MT Pro Control, Max Swing 920mm, Spindle Motor 45kW, Rotary Spindle Motor 37 kW, Max Spindle Speed 1600rpm, Spindle Bore 260mm Dia, X/Y/Z Travels 1025/650/2106mm, B-Axis -30deg/+210deg, C-Axis 360deg, Rapids X/Y/Z 40/40/40m/min, Max Rotary Tool Spindle Speed 10,000rpm, Tailstock Travel 1858mm, Tailstock Quill Stroke 160mm, Tailstock Centre MT6, Automatic 80 Position Toolchanger, Spindle Taper Capto C8, Cromar Swarf Conveyor. Country of Origin: Japan

Please Note: There are no loading facilities on site, dismantling and loading will be at the cost of the purchaser.

Bystronic Xact Smart 225/4100 Hydraulic Press Brake. S/No. XACT21278SE (08/2021), Max Press Force 2250KN, Max Working Length 4100mm, Max Stroke 200mm, Rapid Approach 140mm/s, Working Speed 1 - 10mm/s, Return Speed 115mm/s, Machine Weight 15,000kg. Country of Origin: China

Doosan Mecatec S550LM Slant Bed CNC Lathe with Fanuc Series 21i – TB CNC Control, Swing Over Bed 710, Distance between both Centres 1230mm, Max Turning Diameter 480mm, Max Turning Length 1130mm, Spindle Speeds 30 – 2500rpm, 12 Tools VDI40 Turret, X Axis Travel 300mm, Z Axis Travel 1150mm, Live Driven Tools, C Axis, Machine Weight 8000kg. S/No. LNY – 1008 (2004). Country of Origin: Korea

Location: This lot is located in Birmingham, UK. A charge of £550 for dismantling and loading onto suitable transport will be automatically added to your invoice should you be successful in purchasing this item. Blocking and securing will be at the cost of the purchaser.

Kaltenbach TL350 Upcut Mitre Saw with 7 Metre Graduated Guide Infeed, 350mm Blade, 90 deg of Mitre Adjustment, Manual Black Operation. S/No. 113199 (1990) 113200 (1990). Country of Origin: Germany

Sunnen GH210 Horizontal Hone with Siemens Simatic Control (2010), Max Stroke 7600mm, Spindle Speed: 0 - 300rpm, Maximum Spindle Power: 40 Hp (29.83 kW), Maximum Stroker Power: 18 Hp (13.42 kW), Stroke Speed Range: 0 – 100 ft/min (0 – 30.5 m/min), I.D. Range: 2 – 24 inches (50.8 – 609.6 mm), O.D. Range: 26 inches Standard (660.4 mm), Maximum Part Weight: 8000 kg, Approximate Machine Weight: 12,066 kg, 400 VAC 50 Hz, 3-Phase (85 A)

OFFERS CONSIDERED PRIOR TO AUCTION

10 Bin Food Grade Multi Head Filling Machine complete with Loading Hopper with 300kg Capacity, Hopper feeds Bucket Elevate on Machine demand and applies product into Multihead Bins to service Doypack Machines. Can be set up on dual floors (as pictured) or utilise Tower Framework. All Multihead Bins are serviceable and can be cleaned down, PLC Controls allow programming both in Multihead Element but also on the Doypack Machines. (2022)
